What is atmospheric optics about?
Atmospheric optics is the collective name to all phenomena occuring in nature with respect to weather, having to do with light - light tricks of nature. This includes phenomena like the common rainbow, the reddening of sunset, colored arcs around the sun and moon due to ice-crystal clouds and so on. There is a huge number of phenomena possible - most of which are unknown to most people. Yet atmospheric optics can be a very intriguing field of study, and photography

About the photography
Camera
For photography of optical phenomena, I recommend you to have a manual camera ready all the time at home, and a small compact camera with you all the time. Better is to have the manual camera with you but this is quite bulky and heavy to carry around. Make sure both cameras are loaded with film all the time, and you have a few new rolls of 36 exposures each ready.

Both the manual and the compact camera should have the Bulb setting 'B' for manual shutter control. This is handy in case you have to photograph a halo around the moon, in which case you may need to expose the photo about 10 seconds or so.

Do not buy an APS compact camera, but a 35mm camera.


Camera lenses
Choose a compact camera with a good quality lens on it. Fixed-size lenses are better than zoomlenses, however, some subjects may be very tiny if photographed with a wide angle lens, and the film granulariry will actually cause the photo to be less quality than the same photo if taken with a zoom lens zoomed in to the subject. (I myself decided to buy a compact camera with a zoomlens on it, made by Schneider.)

For the manual camera, you should have a wide variety of lenses available. Do not use zoomlenses with the manual camera, as the camera system is composed of a body and separate lenses, anyway. Obtain the following lenses (I assume you have a standard 35mm manual camera like the good old Praktica):

16 mm fish-eye (or 180 deg. angle adapter): Necessary for capturing a halo display with all arcs appearing on the same photo. This is useful for analysis of the photos later on. If you only make normal-view photos of all halos, parhelia and arcs, it is not clear which arcs were visible at the same moment. Also, a fish-eye lens is nice to have if you want to capture the all-sky view of a sunset with twilight arc in the west and the earth's shadow in the east, for example.

Note: if you don't buy a fisheye standalone lens but a fisheye converter, you will save much money, and you can mount the adapter to every other type of lens, so you can make other lens systems, for example, a lens system with 100 deg. view. Really handy in case you need to photograph the 46 deg. halo in its entirety, for example!
To give you an idea of the price of a fisheye converter: I bought mine second-hand, one (a true 180 deg. fisheye converter) for and the other (a semi-fisheye converter with 150 deg. view) for .

28 mm wide-angle lens: This lens is the most important lens to have. Keep this one on the camera all the time, when not using it. When an optical phenomenon suddenly occurs, you can take action immediately, without first having to change lenses (Prakticas have lenses that must be screwed on and off the camera, really awesome work if you're in a hurry!)

50 mm standard lens: This is nice to have the smaller phenomena larger in view, like heiligenschein, antisolar rays, coronas and glories, to name a few.

135 mm telelens: Necessary to photograph phenomena with even smaller extend, like a localized iridescent cloud, a corona aureole, a roadway mirage, etc.

1000 mm telelens: Necessary to photograph the sun showing a green rim, green segment, green flash, Chinese-lantern-effect, and for photographing all sorts of horizon mirages.


Filters
The third thing you may want to have is a filter. There are two kinds of filters interesting for color photography of atmospheric optical phenomena: the UV filter and the polarizing filter. The UV filter is - I think - not that necessary, as most modern lenses have UV coatings of their own, and film nowadays is much less sensitive to UV light than in earlier days.

However, the polarizing filter is very useful. Light reflected and refracted by ice crystals and water droplets becomes linearly polarized, that is, the light waves have a certain transversal, linear orientation. The filter only passes light of a certain linear polarization direction, and by rotating the filter around for 90 degrees, the light wave will either be fully transmitted, not at all transmitted, or partially.

In effect, you can play with the intensity of a phenomenon like a parhelion by simply rotating the filter on the camera lens, and go for maximum contrast of the effect.

Secondly, the blue sky is also linearly polarized, most at 90 degrees away from the sun, and the sky light can be drastically reduced in this direction by adjusting the filter rotation.

There are two types of polarizing filters: linear and circular. The circular filter is better to have, especially when using a camera with an autofocus lens, or a zoomlens. It is also more expensive than a linear filter. However, for this purpose, the filters have the same effect - increasing contrast.




General Notes
Photography of atmospheric optical phenomena is not difficult, if you don't want to spend too much time and money in photography equipment. There is basically just one difficulty: as with all weather phenomena, atmospheric phenomena happen much at random and usually unexpectedly. So you must have a camera with you all the time, with enough film. Every new day might bring a terrific halo display, showing many halos, parhelia and arcs in the sky. It is a great relief to have a camera with you at such a moment!


Obviously, you can't always carry all this photography equipment with you. Just the compact camera for the just-in-case option. This is a must! I have been able to photograph a very rare and fine pyramid-ice-crystal halo display over Amsterdam, The Netherlands, because I decided that morning, after some consideration, that I should take my camera with me that day.

Watch the sky and ground often, in search of phenomena. It is absolutely necessary to study some books about atmospheric halos, sunsets, and other phenomena. Then you know where to look, what to expect, and how to act to get the best view of a phenomenon. Especially the halos, parhelia and arcs will easily remain unnoticed if one does not know that it could be there. For example, I occasionally see part of a parhelic circle, just because I see a bright upper tangent arc and a 22 deg. parhelion, and I then know there are ice crystals in the atmosphere overhead, oriented favorably for a parhelic circle to show up. The parhelic circle would otherwise completely get lost in the cloud background (aircraft contrails make it even more difficult to discover).

Feed the obsession: Read books, and watch out for any phenomena you have just read about. It is very rewarding to see a (maybe rare) phenomenon that you read about in the books. That stimulates the interest even more, so you start reading more books and internet sites, learn more, and therefore see much more in nature. It is a self-feeding process, and it makes you a happy man or woman. (For me, my life would not be half that much fun if I did not have this obsession in which I can completely get lost!)

If you are not much into atmospheric optics, are reading this, and decide to start the hobby, I am much delighted, as is atmospheric optics science also. Many predicted (and undoubtedly unpredicted) phenomena remain undiscovered or unphotographed, and an increasing number of observers increases the chance of new discoveries.
